Product Specifications

--

Product Description

Overview

Quick Details

Place of Origin:Hubei, China

Brand Name:WELLSEE

Model Number:WS-MPPT60

Type:MPPT

Application:Charger Controller, Solar Working Station, Lighting Controller, Voltage Controller, Solar System Controller

Work Time (h):24hours

Max PV Power:1440W

Max PV Voltage:48V

Product name:MPPT Solar Charge Controller

Charge mode:MPPT Charging

Color:Silver

Display:Led

System voltage:12v/24v Automatic Recognition

Battery type:Sealed Gel AGM Flooded Lithium

Function:Electronic Multi Protective Function

Charging current:60 Ampere

OEM:Avaliable

Certification:CE RoHS ISO9001

Packaging & Delivery

Selling Units:Single itemSingle package size:  24X15X7 cm Single gross weight: 1.200 kgPackage Type:16pieces/carton Picture Example:

Lead Time :

Online Customization

Product Details

WELLSEE China factory price mppt controller 60A Maximum Current WS-MPPT60 controlador de carga solar mppt CE,RoHS

WS-MPPT60 40A/50A/60A 12V/24V mppt solar controller (also known as WELLSEE intelligent solar charge controller, solar charge controller, PV controller) can intelligently regulate the working voltage of solar panels, letting the solar panels always work at Maximum Power Point of V-A curve. Compared with standard solar controller, this MPPT controller can increase the efficiency of PV modules by 10%-30%. WELLSEE WS-MPPT solar controllers 10A--60A include 12V series, 24V series and 48V series.

Product Details Show

Product Parameters

Product Introduction

WELLSEE China factory price mppt controller 60A Maximum Current WS-MPPT60 controlador de carga solar mppt CE,RoHS

MPPT advantage:

Maximum Power Point Tracking (MPPT in short) system allows PV panels to output more Power by adjusting working condition of the electrical module. In Figure1 A indicates that the working state of ordinary controller, that is PV battery working on 12V ,only outputting a power point of 53W (the general power point), B indicates that MPPT controller makes PV battery always work at the maximum power point, thus outputting the power point of 75W (the maximum power point).

Product features:

Applicable to various types of batteries,

MPPT function

Microprocessor controller pulse width modulation (PWM) charging

Temperature sensor battery charging compensation

Overload protection (automatic restoration)

Overcharge protection

Short circuit protection (automatic restoration) ,

Lightning protection

Reverse discharge protection

Reverse polarity connection protection (automatic restoration)

Under voltage protection

MPPT principle:

The maximum power point is mainly affected by the ambient temperature and the intensity of sunshine. With the intensity of sunshine being constant, the maximum output power decreases with the rise of the temperature. The temperature being constant, when the sunshine intensifies, the open circuit voltage of PV battery basically keeps unchanged. But the short circuit current increases substantially, thus the maximum output power increases substantially.

This WS-MPPT solar controller can intelligently regulate the working voltage of solar panels, letting the solar panels always work at Maximum Power Point of V-A curve. Compared with ordinary solar controller, this MPPT controller can increase the efficiency of PV modules by about 30%.

However, due to many different factors, such as the difference in solar panel making, the change of the sun illuminance, change of temperature, the efficiency of the controller etc., the actually available increased rate is 10%-30%.

We are the super-scale research and development enterprise for solar charge and discharge controller, the supplier of WELLSEE solar controller, photovoltaic system equipment. WELLSEE has passed the ISO9001, CE and ROHS certifications. We can design and produce according to clients special request. Welcome to be our agents.

We research, develop, manufacture and export the following products:

1.Bluelight therapeutic apparatus: BL-EX, BL-F,BL-FB,BL-G

2.Wellsee solar photovoltaic power syetem and wind power:

a.wellsee 3-stage charge controller: 12V/24V/48V 15A- 60A-120A

b.mppt solar controller: 12V/24V/48V 30A -60A.-80A

c. solar street light controller: 12V/24V/48V 10A-60A

d. wind/solar hybrid controller: 12V/24V 30A

e. wind turbine: 12V/24V 300W/400W/500W/600W/800W/1KW/10KW

f.solar inverter: 12V/24V/48V/96V 1000W--6KW

g. car inverter: 12V/24V 200W -2000W

Any question, welcome to contact us WELLSEE team

CE,RoHS certification

WELLSEE charge controller could store DC generated by solar panels intobattery, which could effectively provide living and industrial using electricity in some remote areas and tourism destination areas where have no electric power facilities and electricity network, and have no negative effect on environment.

Why Choose Us

About us

1, Wuhan Wellsee New Energy Industry Co., Ltd, inversted by Hubei Bluelight Science & Technology Development Co.,Ltd, is a big manufacturer of researching and producing solar controller, wind turbine generator,wind controller,solar inverter, automotive inverter and other alternative energy products.

Quality & Certification

2, WELLSEE regards the quality and prestige as the supreme, which puts itself under the surveillance of clients and administrative departments. It has released the Guarantee on Quality and Credibility solemnly.Wellsee dedicated to the research and development of  technological innovation new energy products,which have successfully got the CE and RoHS certification

Service

3,WELLSEE offers complete services (called Ten Reliable Services) in the whole procedure of sale and promises that it will try its best to be honest, efficient and speedy. The WELLSEE's behavior principle is Honestly to be a man, while wisely a merchant.

Provide professional sevice,fast goods delivery.perfect After-sales Service .

WELLSEE teams welcome your long terms cooperation.

Product Processing

Product Packing
